Chain / Lever Hoist

chain hoist

Harrington CF hand chain hoists give you a practical alternative thanks to an economical design using fewer parts for trouble-free service. Outstanding durability is due to a die-cast aluminum body and high-strength, heat-treated main pinion shaft and load gear. Pre-lubricated ball bearings, precision machined gears, and Weston-style load brake make lifting smooth and easy while allowing long service and low maintenance.

Many Benefits From More Features:

  • Experience exceptional strength with a thick die-cast aluminum body.
  • Handle tough demands with high-strength, heat-treated main pinion shaft and load gear.
  • Get positive braking action with Weston-style load brake incorporating two moisture-resistant brake pads with four braking surfaces.
  • Minimize manual effort thanks to smooth running, pre-lubricated ball bearings, and precision machined drive train components.
  • Simplify maintenance with fewer parts and an easy-to-work-on design.

Capabilities To Count On:

  • 10-foot lift is standard, 15 and 20-foot lifts are also stocked; nonstandard lifts and hand chain drops available as well.
  • Grade 100 heat-treated manganese alloy load chain resists abrasion and wear while minimizing chain weight.
  • Forged and heat-treated alloy steel hooks are designed to open slowly and not fracture under excessive loads.
  • Test certificate verifies that every hoist has been factory load tested to 125% of rated capacity, in accordance with ASME B30.16 requirements.

Options:

  • Chain container
  • Corrosion-resistant chain
  • Inspection hook
Product Description
CF Hand Chain Hoist – Dimensions
Cap. (Tons) Product Code a (in) b (in) d (in) e (in) f (in) g (in)
1/2
CF005 5.4 5.9 10 2.0 2.4 1.1
1
CF010 5.8 6.9 10 2.3 2.9 1.1
1 1/2
CF015 6.0 8.0 10 2.4 3.4 1.3
2
CF020 5.8 8.0 10 2.3 2.3 1.4
3
CF030 6.0 9.4 10 2.4 2.7 1.7
5
CF050 6.0 13.5 10 2.4 4.5 1.8
chain hoist diagram
Product Description
CF Hand Chain Hoist – Specifications
Cap. (Tons) Product Code Headroom C (in) Std. Lift (ft) Pull to Lift Load (lbs) Overhaul Ratio Load Chain Diameter (mm) x Chain Fall Lines Net Weight (lbs) Shipping Weight Approx. (lbs) Weight for Additional One Foot of Lift (lbs)
1/2
CF005 12.8 10 60 19 5.0×1 24 26 1.0
1
CF010 14.6 10 72 31 6.3×1 29 31 1.2
1 1/2
CF015 17.3 10 84 41 7.1×1 40 42 1.4
2
CF020 20.1 10 80 63 6.3×2 47 49 1.8
3
CF030 23.2 10 92 81 7.1×2 62 66 2.1
5
CF050 24.4 10 92 134 7.1×3 82 86 2.9

Lever Hoist

lever hoist

The LB series of lever hoists offers a low headroom, compact design that is perfect for use in tight quarters. Regarded as the best lever hoist in the industry, our LB is recommended for use in heavy duty construction work, mining, manufacturing, shipbuilding, and day-to-day maintenance and repair.

Many Benefits From More Features:

  • Rugged, all-steel construction that actually weighs less than comparable aluminum models.
  • Get positive braking action with Weston-style load brake incorporating two moisture-resistant brake pads with four braking surfaces. Includes two brake pawls for additional reliability.
  • Enjoy protection against dirt and moisture with a totally enclosed brake mechanism.
  • Ensure long life with machined, heat-treated, split load double reduction gears.
  • Operate in close quarters with short steel handle and 15-degree recovery strokes.
  • Patented spring-loaded freewheel mechanism permits easy adjustment of the load chain and safeguards against accidental freewheeling under load.
  • Equipped with standard rubber grip for non-slip operation.

Capabilities To Count On:

  • 5-foot lift is standard, 10, 15, and 20-foot lifts also stocked; nonstandard lifts available as well.
  • Grade 100 heat-treated load chain is nickel plated for corrosion resistance.
  • Forged and heat-treated alloy steel hooks open slowly without fracturing under excessive loads. Top and bottom hooks rotate 360.˚
  • Test certificate verifies that every hoist has been factory load tested to 125% of rated capacity, in accordance with ASME B30.21 requirements.

Options:

  • Load limit warning handle
  • Top hook extender
  • Point load hook
  • Slip clutch
  • Inspection hook
  • Bullard® and Shur-Loc® hooks
lever hoist diagram
Product Description
Cap. (Tons) Product Code Headroom C (in) Std. Lift (ft) Pull to Lift Load (lbs) a (in) b (in) D* (in) e (in) f (in) g (in) Load Chain Diameter (mm) x Chain Fall Lines Net Weight (lbs) Shipping Weight Approx. (lbs) Weight for Additional One Foot of Lift (lbs)
3/4
LB008 11.0 5 54 (36) 5.7 4.7 9.6 (14.4) 3.8 1.6 0.9 5.6×1 13 13 0.5
1
LB010 11.8 5 72 (46) 5.7 4.7 9.6 (14.4) 3.8 1.6 1.1 5.6×1 13 14 0.5
1 1/2
LB015 13.2 5 64 (45) 6.3 5.0 10.4 (14.4) 3.9 1.5 1.3 7.1×1 18 18 0.7
2
LB020 14.8 5 59 (42) 6.8 5.9 10.4 (14.4) 4.0 1.8 1.4 8.8×1 25 26 1.1
2 3/4
LB028 14.8 5 81 (57) 6.8 5.9 10.4 (14.4) 4.0 1.8 1.4 8.8×1 25 26 1.1
3
LB030 15.6 5 69 7.5 6.3 16.3 (16.9) 4.4 1.8 1.5 10.0×1 33 35 1.5
6
LB060 21.3 5 72 7.5 8.5 16.3 (16.9) 4.4 2.3 2.0 10.0×2 57 60 3.2
9
LB090 26.8 5 78 7.5 12.0 16.3 (16.9) 4.4 4.1 2.9 10.0×3 88 93 4.7

*Figures in parentheses are for hoists with the optional load limit warning handle.

Lever Puller

lever puller

Harrington’s LX mini puller is lightweight, compact, and built to perform. It fits conveniently in a toolbox and will easily handle pulling and moving jobs in many applications including transportation, construction and plumbing. Available in two capacities to fit all applications. The 1⁄2-ton capacity is unique to the industry.

Many Benefits From More Features:

  • Durable die-cast aluminum body with steel frame is compact and lightweight.
  • Very low headroom design for use in tight spaces.
  • Free-chain mechanism allows for quick adjustments.
  • Extremely low pulling force is required for operation.
  • Weston-style brake is totally enclosed to protect against dirt, dust and rain.
  • Single step reduction gear assures load holding performance.
  • Load chain guide mechanism permits smooth and quiet guiding of chain.
  • Rubber handle grip for ease of use.
  • Effortless to transport, install, and store.

Capabilities To Count On:

  • Grade 100, nickel-plated load chain is corrosion and wear-resistant.
  • Strong hook latches include notched tip.
  • 5-foot lift is standard. Longer lifts are available in both capacities.
  • Sold individually or in convenient multi-packs— 1⁄4 ton in 6-packs and 1⁄2 ton in 4-packs.
  • Test certificate verifies that every hoist has been factory load tested to 125% of rated capacity in accordance with ASME B30.21 requirements.

Options:

  • Heavy duty carrying case
lever puller diagram
Product Description
Cap. (Tons) Product Code Headroom C (in) Std. Lift (ft) Pull to Lift Load (lbs) a (in) b (in) D (in) e (in) g (in) Load Chain Diameter (mm) x Chain Fall Lines Net Weight (lbs) Shipping Weight Approx. (lbs) Weight for Additional One Foot of Lift (lbs)
1/4
LX003 8.1 5 40 3.5 2.9 5.9 2.4 0.8 3.2×1 3.5 4.0 0.15
1/2
LX005 9.7 5 62 3.9 3.7 7.1 2.7 0.9 4.3×1 5.7 6.2 0.25

Weights are approximate.
